Hatch Lifter System Parts (7)
-
Self Contained Hatch Lifters (2)
-
Clevis Mounts for HL-18 & HL-24
$38.00Hatch Mounts Manufactured From Solid Aluminum Stock. Pre-Drilled
For Easy Installation. Hatch Mount Can Be Threaded To Allow Removal
From Outside Of Hatch In Emergency. Rod End Clevis And Cylinder
End Clevis Both Supplied With Pins.
Code#CM100 -
Cylinder 18″ Stroke
$278.00FOR USE ACTUATING HATCHES OR DOORS
26″ Retracted Length With An 18″ Stroke
44″ Extended Length
6063T832 Hard Coat Anodized Aircraft Grade Aluminum Tube 1″ Bore With 5/8″ Stainless Steel Shaft.
Double Acting Cylinder, Power-Up/Power-Down
For Mounting Use CM100 Stainless Steel Clevis
Code#CYL18 -
Cylinder 24″ stroke
$298.0032″ Retracted Length With A 24″ Stroke
56″ Extended Length 6063T832 Hard Coat Anodized Aircraft Grade Aluminum Tube 1″ Bore With 5/8″ Stainless Steel Shaft.
Double Acting Cylinder, Power-Up/Power-Down.
Code#CYL24 -
Hatch Lift Power Unit 2-Wire Motor 4-Hose Pump
$438.00Hatch Lift Power Unit 2-Wire Motor 4-Hose Pump to replace power unit on PT417N
For a new Installation, purchase PT417N that is complete with mount bracket & relays.
Code#PT406N-4P -
Hatch Lift Power Unit 2-Wire Motor 4-Hose Pump Mounted on Aluminum Bulk Head Mount Bracket Wired up
$578.00Complete Power Unit with Bulkhead Mount Plate and Relays.
Wired ready to hook up.
This pump is to be used with 2 CYL18 or CYL24 cylinders to make a hatch lift system that can lift up to 1,000 LBS. This system make a great replacement for electric hatch lifters that have failed.
Requires 4 Hoses & 4 CM100 Clevis Mounts
Please call for application assistance. 954-975-7373
Code#PT417N -
Hatch Lift Power Unit 2-Wire Motor 4-Hose Pump Mounted on Stainless Steel Floor Mount Bracket Wired
$578.00Complete Power Unit with Floor Mount Bracket and Relays.
Wired ready to hook up.
This pump is to be used with 2 CYL18 or CYL24 cylinders to make a hatch lift system that can lift up to 1,000 LBS. This system make a great replacement for electric hatch lifters that have failed.
Requires 4 Hoses & 4 CM100 Clevis Mounts
Please call for application assistance. 954-975-7373
Code#PT416N -
Hydraulic Hatch Lifter Self Contained with an 18″ Stroke
$658.00HL18HD consists of a Hydraulic Pump Mounted on a Cylinder and totally Self Contained
Cylinder Tube is Aircraft Quality 6063T832 Hard Coat Anodized Aluminum. The Rod is 5/8″ Stainless Steel with an Aluminum Clevis
Cylinder Length is 26″ on centers Retracted with an 18″Stroke
The Extended Length is 44″
The 12 Volt DC Motor is SAE J1171Marine 2-Wire Permanent Magnet type
The Maximum Hatch weight is 500 Pounds
For larger boats with Heavier Hatches up to 1000 Pounds we recommend using 2 Cylinders and 1 Heavy Duty Hydraulic Pump
Call the factory for help designing a Hatch Lift System for boats that require a system to handle weights exceeding 500 pounds
Code#HL18HD -
Hydraulic Hatch Lifter Self Contained with an 24″ Stroke
$658.001″ Bore Cylinder 32.00″ On Centers Retracted Length With An 24.00″ Stroke And A 56.00″ Extended Length
Motor Is SAE J1171 Marine
Code#HL24HD
